产品特点

Key Specifications
CPU: OTS-FNR-16 / 25 / 32: 6th-generation Intel processor, Dual Core 3.7 GHz or higher / OTS-FNR-45 / 64: 6th-generation Intel processor, Quad Core 3.4 GHz or higher
RAM: OTS-FNR-16 / 25: 8 GB or higher / OTS-FNR-32 / 45 / 64: 16 GB or higher
Default Storage: SSD 120 GB
Expandable Storage: Up to 50 TB
Video Input
OTS-FNR-16 : 16 CH
OTS-FNR-25 : 25 CH
OTS-FNR-32 : 32 CH
OTS-FNR-45 : 49 CH
OTS-FNR-64 : 64 CH
Video Output
VGA x1 / DVI x1 / HDMI x1
Screen Split
Multi-Monitor Support: 2 monitors supported by default (up to 4 monitors optional)
Monitoring / Recording Resolution
OTS-FNR-16 : 480fps
OTS-FNR-25 : 750fps
OTS-FNR-32 : 960fps
OTS-FNR-45 : 1470fps
OTS-FNR-64 : 1920fps
Monitoring / Recording Frame Rate
OTS-FNR-16 : 480fps
OTS-FNR-25 : 750fps
OTS-FNR-32 : 960fps
OTS-FNR-45 : 1470fps
OTS-FNR-64 : 1920fps
Compression Method
Video Codec: H.265, H.264, MJPEG, MPEG4, MPEG2
Audio Codec: G.711, G.723, G.726
Recording Mode
Continuous, Motion, Event, Scheduled
Search Mode
Supports 5-level alarm settings, real-time video pop-up, audio alarm, and alarm functions / Built-in support for IP camera motion events and program-based motion events
Expansion Interface
Serial Interface: RS-485, RS-232 (USB Type)
NIC
1 Gbps
Network Software
Protocol: ONVIF, RTSP
DDNS: Dedicated DDNS Server Operation
TCP: Unicast TCP, Multicast TCP
Smart Devices: Android, iPhone
Other Features
Time Synchronization (RTFC): SafeTok (Optional)
Backup Method: Built-in video backup / Network backup supported
File Formats: AVI, MOV, MP4, Proprietary Format, CMS Remote Backup, Encrypted Backup
Data Backup
ocal Backup, Network Backup
Power Supply
AC110~220V, 50/60Hz
Weight
15kg
Dimensions
482.6mm x 177mm x 517.75mm
